M7285C1009 Honeywell Actuator – 120 V Spring-Return Modulating Actuator

THE HONEYWELL M7285C1009 34VA, 120V 50/60HZ. 90 DEG ADJ STROKE. 30-60 SEC TIMING. 60 LB-IN TORQUE. WITH Transformer AND TERMINAL Adapter Spring RETURN, NORM CLOSED 4-20 MA INPUT, 2 AUX Switch, DUAL Shaft

M7285C1009 Honeywell Actuator – 120 V Spring-Return Modulating Actuator Datasheet

Overview of M7285C1009 Honeywell

The Honeywell M7285C1009 is part of the Modutrol IV actuator family. Designed for HVAC and burner control systems, this spring-return actuator provides fail-safe positioning when power is lost. With 60 lb-in torque, 4–20 mA modulating input, and dual internal auxiliary switches, it delivers precise control of dampers and valves in demanding environments.

Specifications

Features & Benefits

• Spring-return fail-safe protects equipment by moving to a safe position on power loss

• Precise modulating control with 4–20 mA input for accurate damper and valve positioning

• Adjustable stroke from 90° to 160° for versatile applications

• Dual auxiliary switches provide feedback or additional control logic

• Durable design built to perform in demanding HVAC and industrial settings

• Dual shaft outputs allow flexible linkage connections

Applications

• Commercial and industrial HVAC dampers

• Hydronic valves in heating, cooling, or mixing systems

• Combustion air and burner control systems

• Retrofit upgrades for older actuators requiring fail-safe operation

• Integration with building automation and energy management systems

Installation & Maintenance

• Mount actuator securely on valve or damper with proper linkage alignment

• Adjust zero and span to match travel requirements

• Ensure smooth, nonbinding linkage operation

• Periodically verify auxiliary switch function

• Keep actuator free of dust, dirt, and condensation

• Do not manually force the shaft to prevent gear damage
