VG7241LT Johnson Controls Valve

Overview

The Johnson Controls VA-7010-8002 is an electric valve actuator designed to provide two-position (open/closed) control for commercial HVAC systems. This line-voltage actuator easily mounts onto VG4400, VG4500, VG4800, and VG5000 series forged brass zone valves via a threaded coupling. It includes a manual lever on the side of the housing for manual override and servicing.

Features

• AC stall-type motor ensures quiet operation and longevity.
• Manual operating lever allows manual position mode for system servicing.
• Flat profile design with minimal side clearance saves space in tight installations.
• Actuator can be mounted after the valve body is installed, simplifying confined space applications.
• Rotatable after mounting to allow easy wiring conduit entry in any direction.

Specifications

• Supply Voltage: 120 VAC, 50/60 Hz
• Power Consumption: 7 VA
• Control Signal: On/Off (Two-position)
• Force: 20.2 lb (90 N) minimum
• Nominal Stroke: 0.12 inches (3 mm) to 0.2 inches (5 mm) maximum
• Full Stroke Time: 10 seconds nominal On, 5 seconds nominal Off
• Enclosure Rating: IP40, NEMA 1
• Ambient Operating Temperature: 35 to 122 degrees Fahrenheit (2 to 50 degrees Celsius)

Applications

• Used in fan coil units, terminal units, and zoning applications within commercial HVAC networks.
• Field-mounted onto Johnson Controls VG4400, VG4500, VG4800, and VG5000 series zone valves.
• Suitable for two-position control of chilled water, hot water, and low-pressure steam lines in building automation systems.
