VG7241ET+7152G Johnson Controls Valve / Actuator

Overview

The Johnson Controls SEN-600-1 is a wall-mounted remote indoor temperature sensor designed to provide precise temperature monitoring for commercial HVAC applications. It features an integral sensing element and internal circuitry that allows it to seamlessly interface with T600 Series programmable and non-programmable thermostats, as well as TEC2100 Metasys system N2 networked thermostats. This sensor allows for remote temperature sensing, enabling the thermostat to be installed in a separate, secure location away from the controlled space.

Features

• Wall-mounted indoor design suitable for commercial environments
• Powered directly by the connected T600 or TEC2100 thermostat, eliminating the need for an external power source
• Supports temperature averaging configurations, allowing up to three remote sensors to be wired together to provide a uniform zone reading
• Clean, low-profile white enclosure that fits standard interior decors
• Simple installation process with standard mounting holes and wire connections

Specifications

• Manufacturer: Johnson Controls
• Part Number: SEN-600-1
• Sensor Type: 10k Ohm NTC (Negative Temperature Coefficient) thermistor
• Nominal Resistance: 10,000 ohms at 77°F (25°C)
• Sensor Accuracy: ±0.5 C° from 0 to 70°C (±0.9 F° from 32 to 158°F)
• Operating Temperature Range: 32 to 122°F (0 to 50°C)
• Operating Humidity Range: 0 to 95% RH, non-condensing
• Dimensions: Approximately 5 inches height x 4 inches width x 1 inch depth
• Display: None
• Occupancy Override: No

Applications

• Remote indoor temperature sensing for commercial and institutional HVAC systems
• Spaces where the thermostat needs to be protected from public tampering, adjustments, or vandalism
• Temperature averaging configurations across large open offices, retail spaces, or multi-room zones using up to three connected units
• Integration with Building Automation Systems (BAS) via T600 Series and TEC2000/TEC2100 Series network thermostats
