VB-9213-0-5-15 Schneider Electric Valve Body
Valve,Globe, 5″, Flange, Two-way 235 Cv Equal Percentage Flow ANSI Class 125 Cast Iron Body with Brass Trim, Stem Up Open
Valve Body (VB-9213-0-5-15):
- Body Size: 5 in
- Configuration: 2-Way
- Type: Globe
- Connection: Flanged
- Stem Flow Action: Stem up A open
- Material Trim: Brass
- Flow Coefficient: 235 cv
- Control Media: Steam, Water
- Product Line: Schneider Electric
- Product Series: VB-9200
Product Specifications
| Body Size | 125 mm (5 in) |
| By Schneider | Yes |
| California Residents |  WARNING:This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Configuration | 2-Way |
| Connection Type | Flanged |
| Flow Characteristic | Modified equal percentage |
| Flow Coefficient | 203.25 kvs |
| 235.00 cv | |
| Material Body | Cast iron |
| Material Packing | Spring-loaded PTFE/EPDM |
| Material Plug | Brass |
| Material Seat Port A | Bronze |
| Material Stem | 316 Stainless steel |
| Material Trim | Brass |
| Media Compatibility | Steam |
| Water | |
| Pipe Size | 5 in |
| Pressure Allowable Static | Class 125 with 200 PSIG up to 150 F decreasing to 169 PSIG at 281 F |
| Pressure Class | 125 ANSI |
| Product Series | VB-9200 |
| Rangeability | 75:1 |
| Seat Leakage Port A | ANSI IV (0.01%) |
| Stem Flow Action | Stem up A open |
| Stem Movement | Linear |
| Stroke Distance | 3-1/8 in |
| Temperature Range Fluid | 4 to 138 C (40 to 281 F) |
| Temperature Range Saturated Steam | 4 to 138 C (40 to 281 F) |
| Type | Globe |
| Weight | 142 lbs |
|---|---|
| Dimensions | 39 × 16 × 20 in |
