GVD221.1U Siemens Actuator
$275.09
Fire and Smoke Damper Actuator 200 lb-in 2-position control , Spring Return, 120 VAC compatible with built in Electronic Fuse Link capability. For use on UL-listed smoke control dampers and combination fire/smoke rated dampers. Designed to meet UL555S.
Fire and Smoke Damper Actuator 200 lb-in 2-position control , Spring Return, 120 VAC compatible with built in Electronic Fuse Link capability. For use on UL-listed smoke control dampers and combination fire/smoke rated dampers. Designed to meet UL555S.
Technical Specifications
|
Actuator Type |
Electronic Fire and Smoke |
|
Actuation Style |
Rotary |
|
Control or Fire/Smoke Type |
Fire/Smoke Control Damper |
|
Electronic Fusible Link (EFL) |
YES |
|
Plenum or Standard Rating |
Standard |
|
Torque |
200 lb-in |
|
Fail Safe |
Yes |
|
Spring return function |
Spring return function |
|
Control Signal |
2-position |
|
Positioning time |
Run time for 90° 30s nominal, Spring return 15 s max |
|
Power consumption |
35 VA / 9 VA, Run / Hold |
|
Ambient temperature, operation |
0…140 ºF |
|
Ambient humidity, operation |
95 % r.h. |
|
Angular rotation |
95° |
|
Supply Voltage |
120 VAC |
|
Frequency |
50/60 |
|
Auxiliary switch |
0 |
|
Cable length |
3 ft |
|
Dimensions (W x H x D) |
3.8 x 10.75 x 3.4 in |
|
Material, housing |
NEMA 1 / IP40, plenum-rated plastic, high temperature polymer |
|
Standard |
UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments |
| Weight | 4 lbs |
|---|---|
| Dimensions | 12 × 8 × 8 in |
