GPC121.1P Siemens Actuator
$171.23
Damper
Actuator 35 lb-in, SR, 2PT
OpenAir GPC Series Electric Damper Actuator, spring return, 35 lb-in. For use on economizer dampers and small control dampers
Technical Specifications
|
Actuator Type |
Spring return |
|
Actuation Style |
Rotary |
|
Control or Fire/Smoke Type |
Control Damper |
|
Plenum or Standard Rating |
Plenum |
|
Torque |
35 lb-in |
|
Fail Safe |
Yes |
|
Control Signal |
2-position |
|
Positioning time |
Runtime for 90° 60 s |
|
Position feedback |
No |
|
Power consumption |
Running: 3.4 VA (2.0 W), Holding: 2.6 VA (1.6 W) |
|
Ambient temperature, operation |
-25 to 130 °F, -32 to 55 °C |
|
Angular rotation |
90° |
|
Operating voltage |
24 VAC, 24 VDC |
|
Supply Voltage |
24 VAC/DC |
|
Frequency |
50/60 Hz |
|
Auxiliary Switch |
No |
|
Cable length |
3 ft |
|
Dimensions (W x H x D) |
2.83 x 5.61 x 2.48 in |
|
Material, housing |
NEMA 1, Plenum rated rugged plastic |
| Weight | 4 lbs |
|---|---|
| Dimensions | 12 × 8 × 8 in |
