VA-7153-1001 Johnson Controls Valve Actuator

Overview

The Johnson Controls VG7241GT+423GGA is a high-performance valve and actuator assembly combining a 1/2-inch 2-way cast bronze globe valve with a VA-4233-GGA-2 spring-return electric actuator. It features an equal percentage flow characteristic with a Cv of 4.6, brass trim, and operates as normally open (push-down-to-close). This assembly provides precise proportional control for water and steam systems in commercial building automation and HVAC environments.

Features

• Includes a 1/2-inch 2-way bronze globe valve with an equal percentage flow characteristic
• Equipped with a VA-4233-GGA-2 spring-return electric actuator for reliable failsafe performance
• Utilizes a long-life replaceable ring packing to ensure high operational reliability
• Every factory assembly is tested for tight shut-off
• Features a manual opener for setup and troubleshooting flexibility

Specifications

• Pipe Size: 1/2 inch
• Connection Type: Female NPT
• Flow Coefficient: 4.6 Cv
• Valve Pattern: 2-Way
• Failsafe Action: Normally Open (Push-Down-to-Close)
• Trim Material: Brass
• Input Control Signal: 0 to 10 VDC Proportional
• Supply Voltage: 20 to 30 VAC, 50/60 Hz or 24 VDC
• Maximum Close-off Pressure: 208 psi
• Fluid Temperature Range: 35 to 250°F (2 to 121°C)
• Maximum Steam Pressure: 15 psig saturated steam

Applications

• Designed for precise control of hot water, chilled water, and up to 50% glycol solutions in commercial HVAC systems
• Well-suited for low-pressure steam applications up to 15 psig saturated steam
• Ideal for integration with building automation systems requiring proportional electronic modulation
