V5055C1034 Honeywell Industrial Gas Valve
$990.00
The Honeywell V5055C1034 1 in. NPT Industrial Gas Valve with On-off safety shut-off with double seal; Valve,Gas, 2 Way Normally Closed, 1′, NPT,, two way safety shutoff valve use with natural or lp gas comes with 1/4″ upstream and downstream tap and plug -40/150 degree operating temperature 960cfh on-off safety shut off with double seal
The Honeywell V5055C1034 1 in. NPT Industrial Gas Valve with On-off safety shut-off with double seal; Valve, Gas, 2 Way Normally Closed, 1′, NPT,, two way safety shutoff valve use with natural or lp gas comes with 1/4″ upstream and downstream tap and plug -40/150 degree operating temperature 960cfh on-off safety shut off with double seal
Overview
The Honeywell V5055C1034 is a 1-inch NPT normally closed industrial gas valve designed for safety shutoff service. This two-way valve is engineered to control gas flow to commercial and industrial burners. It features an on-off safety shut-off mechanism with a robust double-seal design to ensure tight shutoff and prevent leakage. It is typically used in conjunction with Honeywell fluid power actuators to provide reliable operation in demanding heating applications.
Features
- Designed for use with natural or liquefied petroleum (LP) gases
- Features a double-seal construction for enhanced safety and leakage prevention
- Normally closed valve rated for final safety shutoff service
- Mounts directly into the gas supply line for simplified installation
- Includes 1/4 inch NPT upstream and downstream taps with plugs for pressure testing and monitoring
- Provides proof-of-closure switch and valve seal over-travel interlock when used with V4055D or E actuators
- Constructed with unpainted die-cast aluminum for durability
Specifications
| Includes | 1/4 in. -18 NPT upstream tap and plug, 1/4 in. -18 NPT downstream tap and plug |
| Used With | V9055; V4055; V4062 |
| Item Type | Product |
| Approvals, Underwriters Laboratories Inc. | When used with V4055A,B,D,E, V4062, V9055: Listed, File No. MH1639 Guide No. YIOZ |
| Approvals, Canadian Standards Association | When used with V4055, V4062, and V5097: Certified General listed File No. 158158, Class 3371 for USA and Canada |
| Operating Temperature Range (F) | -40 F to +150 F; When used with V9055– -40 F to +125 F |
| Operating Temperature Range (C) | -40 C to +66 C; When used with V9055– -40 C to +52 C |
| Approvals, Swiss RE | When used with V4055A,B,D,E, V4062, V9055: Acceptable |
| Approvals, Factory Mutual | When used with the V4055D,F and V9055A: Approved, Report Nos. 20698, 20835, 21172, and 24064 |
| Connection Type | NPT |
| Capacity (m³/hr) | 2 m3/hr |
| Pipe Size (inch) | 1 in. |
| Pipe Size (DN) | DN25 |
| Capacity (cfh) | 960 cfh |
| Maximum Operating Differential Pressure | With V4055A,D or V4062– 5 psi (340 mbar); With V4055B or E– 15 psi (1 bar) |
Applications
The V5055C1034 is primarily utilized in commercial and industrial burner systems to regulate the flow of fuel gases. It is specifically designed to work with V4055, V4062, and V9055 fluid power actuators. Common applications include industrial ovens, large-scale boilers, and commercial heating units where reliable safety shutoff and proof-of-closure monitoring are required to maintain safe operating environments.
Additional Information: Honeywell V5055C1034 1″ NPT Industrial Gas Safety Shutoff Valve with Double Seal Click Here
| Weight | 5 lbs |
|---|---|
| Dimensions | 7 × 8 × 7 in |
