P70LB-1C Johnson Controls Pressure Control

Overview

The Johnson Controls VG1245AD+9A4GGA is a factory-assembled 1/2-inch, 2-way characterized ball valve paired with a VA9104-GGA-2S non-spring-return electric actuator. Designed to regulate the flow of hot water, chilled water, or low-pressure steam in commercial Heating, Ventilating, and Air Conditioning (HVAC) systems, this assembly responds precisely to signals from a system controller. It features high-quality stainless steel trim within a durable forged brass body to ensure exceptional performance, accurate control, and a long operational lifespan.

Features

• Long Life Expectancy: Tested and rated to operate reliably for a minimum of 200,000 leak-free cycles, even in challenging iron-oxide contaminated water conditions.
• Proportional Control: Equipped for precise positioning via a 0-10 VDC (or 2-10 VDC) proportional analog input signal.
• High Rangeability: Offers a 500:1 rangeability that ensures highly accurate flow control under varying load demands.
• Advanced Seating & Seals: Utilizes 15% graphite-filled PTFE seats backed with EPDM O-rings for constant seating force, alongside an EPDM double O-ring stem seal for superior leak protection.
• Characterized Flow: Includes an Amodel flow characterizing disk to achieve an equal percentage flow characteristic, providing stable temperature management.

Specifications

• Valve Size & Pattern: 1/2 inch, 2-Way
• Connection Type: Female NPT (National Pipe Thread)
• Flow Coefficient (Cv): 1.2 Cv
• Actuator Type: Electric, Non-Spring Return (VA9104 Series)
• Supply Voltage: 24 VAC (Nominal)
• Input Control Signal: 0(2) to 10 VDC Proportional
• Position Feedback: 0(2) to 10 VDC
• Actuator Torque: 35 lb-in (4 Nm)
• Runtime: 60 seconds
• Static Pressure Rating: 580 psig (PN40)
• Maximum Close-Off Pressure: 200 psid
• Maximum Pressure Drop: 50 psid
• Materials of Construction: Forged brass body, 300 Series stainless steel ball and stem, graphite-reinforced PTFE seats, EPDM O-ring seals, and a PTFE thermal spacer.
• Auxiliary Switch: No switch included

Applications

• Commercial HVAC Systems: Primarily used for regulating hot water and chilled water delivery within building automation architectures.
• Hydronic Control: Ideal for managing fluid flow in fan coil units, unit ventilators, reheat coils, and various hydronic heating or cooling loops.
• Glycol Systems: Suitable for systems requiring temperature regulation utilizing glycol solutions up to 50%.
• Low-Pressure Steam: Designed to handle low-pressure saturated steam applications up to 15 psi due to its durable stainless steel trim configuration.
