129-164R Fireye Disconnect

Overview

The Fireye 129-164R is a specialized quick disconnect (QD) kit featuring a 90-degree angled coupling, specifically engineered for use with Fireye InSight series flame scanners. This angled design is critical for installations with limited clearance or tight wiring paths, allowing for secure signal connections while reducing mechanical strain on cables. It serves as a field-wiring solution to create a serviceable connection point between the scanner and the burner management system.

Features

• 90-degree right-angle plug design facilitates easier wiring in constrained or cramped spaces.
• Simplifies the installation, routing, and servicing of scanner connections in compact control panels.
• OEM-certified accessory ensures full compatibility and secure signal integrity.
• Durable construction reduces cable bending stress, improving the overall longevity of the wiring assembly.
• Creates a convenient, removable connection point for scanner maintenance and replacement.

Specifications

• Manufacturer: Fireye
• Part Number: 129-164R
• Product Type: Quick Disconnect Kit (90-degree angled)
• Compatibility: Designed for use with Fireye InSight I and InSight II scanners
• Design Style: Right-angle / 90-degree coupling
• Materials: High-quality connectors for industrial combustion environments

Applications

• Industrial and commercial flame scanner systems requiring right-angle connector access.
• Boilers, furnaces, and combustion panels with limited wiring clearance or obstructed access.
• Retrofitting existing scanner wiring in tight or compact burner configurations.
• Environments where specific wiring direction constraints exist for safety or space management.
