TE-631GV-2 Johnson Controls Sensor

Overview

The Johnson Controls V46AB-25C is a commercial-grade, direct-acting, pressure-actuated water-regulating valve designed to automatically modulate the flow of water or glycol solutions in response to pressure changes. This self-contained, non-electric valve is primarily utilized to regulate refrigerant head pressure in water-cooled condensers, ensuring optimal temperature control while preventing overheating and excessive water consumption.

Features

• Direct-acting operation where the valve opens on a pressure increase to modulate flow smoothly.
• Robust construction with no close-fitting or sliding parts in water passages, minimizing chatter, water hammer, and performance issues in less-than-ideal water conditions.
• Corrosion-resistant brass body and wetted components that promote a longer operating life.
• Take-apart design allows the interior of the valve to be serviced or disassembled without detaching it from the inline pipe connection or pumping down the system.
• Accessible range spring allows for easy manual flushing or adjustments directly on-site.
• Pressure-balanced configuration ensures the valve maintains a consistent setpoint against sudden or gradual water pressure fluctuations.

Specifications

• Manufacturer: Johnson Controls
• Part Number: V46AB-25C
• Valve Size: 1/2 inch
• Body Style: Two-way configuration
• Connection Type: Threaded NPT (Inlet and Outlet)
• Pressure Connection: 1/4 inch Male Flare Fitting (Style 5)
• Opening Point Range: 70 to 260 psi
• Maximum Temperature: 170°F (77°C)
• Media Compatibility: Water, glycol solutions, and standard non-corrosive refrigerants

Applications

• Regulating water or glycol flow to water-cooled condensers in commercial refrigeration and HVAC systems.
• Optimizing head pressure and temperature regulation in ice machines and commercial ice cream machines.
• Managing environmental controls in computer room air conditioning units and data center cooling configurations.
• Maintaining stable cooling profiles in commercial refrigeration display cases and heat pump applications.
