MS41-6153 Invensys Actuator
$212.50
Invensys MS41-6153 Proportional Actuator, NSR, 24V, 133 lb-in, 0-10 Vdc or 2-10 Vdc; SmartX, Damper Actuator, proportional 0-10 Vdc, non-spring return, 24 Vac, 3 ft appliance cable, 133 lb-in, NEMA 1
Invensys MS41-6153 Proportional Actuator, NSR, 24V, 133 lb-in, 0-10 Vdc or 2-10 Vdc
Actuator: (MS41-6153):
- Actuator Type: Electric
- Control Signal: Proportional
- Control Signal Range: 0 to 10 VDC, 2 to 10 VDC
- Loss of Power Type: Non-Spring Return
- Power Input Voltage: 24 VAC
- Leads and Connections: 3 ft Plenum
- Torque: 133 in-lb
- Mechanical Movement: Rotary
- Protection Rating: NEMA 1
- Product Line: Schneider Electric
- Product Range: SmartX Actuator
- Product Series: Mx4x-6xxx
- Actuator Use: Dampers, Globe Valves
Product Alert: Linkage required for Globe Valve Assembly use.
Product Specifications
| Actuator Housing Material | Aluminum die cast |
| Actuator Type | Electric |
| Actuator Use | Dampers |
| Globe Valves | |
| Auxiliary Switch | 1 SPDT |
| By Schneider | Yes |
| Control Signal | Proportional/Modulating |
| Control Signal Range | 0 to 10 VDC |
| 2 to 10 VDC | |
| Feedback Signal | 0 to 10 VDC |
| Humidity | 5 to 95% non-condensing |
| Insulation Class | Class II |
| IP Protection Rating | IP10 |
| Lead Length | 3 ft |
| Leads and Connections | Plenum |
| Loss of Power Type | Non-Spring Return |
| Mechanical Movement | Rotary |
| Motor Type | AC Synchronous |
| NEMA Protection Rating | NEMA 1 |
| Override | Automatic reset |
| Position Indicator | Pointer and scale from 0 to 90 degrees |
| Power Consumption Running VA | 5.00 VA |
| Power Input Frequency | 50 Hz |
| 60 Hz | |
| Power Input Voltage | 24 VAC |
| Power Input Voltage AC Tolerance | Plus 20% or minus 15% |
| Product Range | SmartX Actuator |
| Product Series | Mx4x-6xxx |
| Rotation | 95 degrees |
| Rotational Range Adjustment | 0 to 95 degrees |
| Temperature Ambient Operating Range | -31.6 to 54.4 C (-25 to 130 F) |
| Temperature Shipping and Storage Range | -40 to 70 C (-40 to 158 F) |
| Torque | 133.00 in-lb |
| 15.03 Nm |
Documents
| File Name | Format | Revision | ||
| Catalog | Valves & Actuators Catalog 2020 North America | 2020 | ||
| Selection guide | Spring-Return and Non-Spring Return Direct Coupled SmartX Actuators | 2020 |
| Weight | 8 lbs |
|---|---|
| Dimensions | 14 × 6 × 4 in |
