MK-2690 Invensys Damper Actuator
$72.50
Invensys MK-2690 Pneumatic Valve Actuator, 6 sq.-in. No Spring (Spring included in AV-400) (12/Case) for 9000 Series Valves AV-7400 for 7000 Series Valves ***TAC EXPRESS***
12 in stock (can be backordered)
Invensys MK-2690 Pneumatic Valve Actuator, 6 sq.-in. No Spring (Spring included in AV-400) (12/Case) for 9000 Series Valves AV-7400 for 7000 Series Valves ***TAC EXPRESS***
Proportional Control, Spring Return, Linear Movement, Nema 1 Enclosure Pneumatic Valve Actuator (6 square inch) with 1/8″ NPT Air Connection and 1/2″ Nominal Stroke (3-7 PSI, 5-10 PSI, or 8-13 PSI range)
Actuator: (MK-2690):
- Actuator Type: Pneumatic
- Control Signal: 2-Position (On/Off), Proportional
- Control Spring Range: 3 to 7 PSIG, 5 to 10 PSIG, 8 to 13 PSIG
- Loss of Power Type: Spring Return
- Leads and Connections: 1/8 in Air NPT
- Mechanical Movement: Linear
- Protection Rating: NEMA 1
- Product Line: Schneider Electric
- Product Series: MK-2690
- Actuator Use: Globe Valves
Product Specifications
| Actuator Diaphragm Material | Neoprene |
| Actuator Housing Material | Aluminum die cast |
| Actuator Type | Pneumatic |
| Actuator Use | Globe Valves |
| By Schneider | Yes |
| California Residents | WARNING:This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Control Signal | 2-Position (On/Off) |
| Proportional/Modulating | |
| Control Spring Range | 3 to 7 PSIG |
| 5 to 10 PSIG | |
| 8 to 13 PSIG | |
| Diaphragm Effective Area | 6 sq in in² |
| Humidity | 5 to 95% non-condensing |
| IP Protection Rating | IP10 |
| Lead Length | 1/8 in |
| Leads and Connections | Air NPT |
| Loss of Power Type | Spring Return |
| Mechanical Movement | Linear |
| Override | 5/32 Allen wrench |
| Position Indicator | Green push stem with color markers |
| Positioner | No |
| Product Series | MK-2690 |
| Stroke Auto Calibration | No |
| Temperature Ambient Operating Range | -28.8 to 104.4 C (-20 to 220 F) |
| Temperature Shipping and Storage Range | -40 to 104.4 C (-40 to 220 F) |
Documents
| Catalog | Valves & Actuators Catalog 2021 North America |
| Weight | 2 lbs |
|---|---|
| Dimensions | 5 × 6 × 4 in |
