MA-5210 Invensys Damper Actuator
$1,002.50
Invensys MA-5210 Two Position Damper Actuator, SR, 120V, 50/60 Hz, 20 lb-in ***TAC EXPRESS***
Invensys MA-5210 Two Position Damper Actuator, SR, 120V, 50/60 Hz, 20 lb-in ***TAC EXPRESS***
Two Position Hydraulic Actuator, 120V, 18VA Input, 14 Watt Input, 15 Second Spring Return, Nema 1
Actuator: (MA-5210):
- Actuator Type: Electric/Hydraulic
- Control Signal: 2-Position (On/Off)
- Loss of Power Type: Spring Return
- Power Input Voltage: 120 VAC
- Leads and Connections: 4 ft Appliance
- Torque: 20 in-lb
- Mechanical Movement: Linear
- Protection Rating: NEMA 1
- Product Line: Schneider Electric
- Product Range: Electronic Hydraulic
- Product Series: MA-5200
- Actuator Use: Dampers, Globe Valves
Product Specifications
| Actuator Type | Electric |
| Hydraulic | |
| Actuator Use | Dampers |
| Globe Valves | |
| Auxiliary Switch | No |
| By Schneider | Yes |
| California Residents |  WARNING:This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Control Signal | 2-Position (On/Off) |
| Humidity | 5 to 95% non-condensing |
| Insulation Class | Class I |
| IP Protection Rating | IP10 |
| Lead Length | 4 ft |
| Leads and Connections | Appliance |
| Loss of Power Type | Spring Return |
| Mechanical Movement | Linear |
| Motor Type | Oil immersed |
| Override | 5/32 Allen wrench |
| Position Indicator | Stroke indicator on bracket |
| Power Consumption Running VA | 18.00 VA |
| Power Input Frequency | 50 Hz |
| 60 Hz | |
| Power Input Voltage | 120 VAC |
| Power Input Voltage AC Tolerance | Plus 10% or minus 15% |
| Product Range | Electronic Hydraulic |
| Product Series | MA-5200 |
| Stroke Auto Calibration | No |
| Temperature Ambient Operating Range | -17.7 to 46.1 C (0 to 115 F) |
| Temperature Shipping and Storage Range | -40 to 60 C (-40 to 140 F) |
| Torque | 2.26 Nm |
| 20.00 in-lb |
Documents
| Catalog | Valves & Actuators Catalog 2020 North America |
| Weight | 3 lbs |
|---|---|
| Dimensions | 8 × 5 × 5 in |
