GQD221.1U Siemens Actuator
$166.39
Spring
Return Rotary, 20 lb-in (2 Nm), 120 Vac, 2-position Control, 30 sec
OpenAir™ GQD Series Electric Damper Actuator, rotary, spring return, 20 lb-in (2 Nm), 120 Vac, 2-position control, 30 sec run time
Technical Specifications
|
Control or Fire/Smoke Type |
Control Damper |
|
Torque |
20 lb-in |
|
Positioning time |
Open:30 s, Close:15 s |
|
Position feedback |
No |
|
Power consumption |
Running: 10 VA, Holding: 7 VA |
|
Ambient humidity, operation |
95 % r.h. |
|
Angular rotation |
90° |
|
Operating voltage |
102…138 VAC |
|
Frequency |
50/60 Hz |
|
Cable length |
3 ft |
|
Dimensions (W x H x D) |
2.72 x 5.5 x 2.47 in |
|
Material, housing |
NEMA 1, plenum-rated rugged plastic, IP40 |
|
Degree of protection |
IP40 |
| Weight | 4 lbs |
|---|---|
| Dimensions | 12 × 8 × 8 in |
