D-3062-4 Johnson Controls Damper Actuator

Datasheet

The Johnson Controls D-3062-4 Damper Actuator; 2″ STROKE; 11-15# Spring 4 SQFT DMPR MAX

The D-3062 Pneumatic Actuator is a multipurpose positioning device used primarily for operating ventilating dampers in response to the output signals of a pneumatic controller or electro-pneumatic transducer.

The D-3062 is also rated for use on life safety dampers up to 250°F. All models are UL Component Recognized.

All models incorporate several internal and external features that add functional flexibility:

• All actuators have a telescoping piston rod for easy linkage to the damper for attachment points up to 5-3/4 inches away from the face of the actuator.
• A swivel ball joint and slotted crank arm connector are furnished for optional methods of linkage to the damper.

The universal mounting bracket is used for damper positioning in two types of mountings:

• duct or wall mounting for both Power Fail Open and Power Fail Closed applications.
• inside frame mounting for Power Fail Closed applications only.
